Tohatsu Motors - MFS4C

Tohatsu 4 Stroke 4HP Outboard Motor
MFS4C



Fundamentals for user convenience and reliability:

 Through-the-prop exhaust for a quieter ride

 Thermostatically controlled cooling system for consistent  engine temperature

 Stainless steel water pump housing for outstanding  durability

 High grade marine aluminium alloy that provides the  ultimate protection against corrosion

 Zinc coating on internal water passages for superior  corrosion resistance

 Internal 1.15ltr Plastic fuel tank with forward of cowl  located fill cap

 Aluminium propeller

 Shallow water drive

 Adjustable steering friction for reducing steering effort



Front shift control Longer tiller handle for ease of control


Protection:

 Low oil pressure indicator

 Safety lanyard (an essential protection feature standard  on all  Tohatsu outboards)

 Start-in-gear protection for safer engine starting



* Certain models



Engine:                                            1-Cylinder

Displacement:                                123cc (7.5 cu. in.)

Bore & Stroke:                                 59 x 45mm (2.32 x 1.77 in.)

Starting:                                           Manual

Controls:                                         Tiller Handle

Gear Shift:                                       Forward - Neutral - Reverse

Gear Ratio:                                      2.15: 1

Propeller Pitch Range:                  8" standard (6"- 9" Optional)

Transom Height:                           15

Fuel Mix:                                         Unleaded Petrol (87 Octane)

Oil Type:                                         Refer Owners Manual

Fuel Tank:                                       1.15ltr Integral Tank

Weight (Min Version):                  26.1 kgs

RPM Range:                                   4,500 - 5,500



** 4hp includes an External Tank Connector installed on engine to allow user to use an optional external fuel tank
