Tohatsu Motors - MFS40A

MFS40A



High performance and easy operation:

Electronic fuel injection

Digital Inductive ignition system for quicker starts

Variable trolling speed for low-speed operation 650-950 rpms

High output alternator producing 21 amps at 3000RPM for battery charging

Large multi tiller handle (tiller version) with steering and throttle friction control, ergonomic designed shift lever, long throttle grip with 110 degree rotation

Handle mounted trim switch (tiller version)

Power trim and tilt

Remote control**

Premium Stainless Steel Bezel Tachometer and trim gauges remote control model*

*Certain models **Remote control models

Fundamentals for user convenience and reliability:

 Stainless steel water pump housing for outstanding durability

 High grade marine aluminium alloy that provides the  ultimate protection against corrosion

 Zinc coating on internal water passage for superior  corrosion resistance

 Thermostatically controlled cooling system

 Through the prop exhaust and unique housing design for a  quite ride

 Plastic 25ltr Fuel Tank with fittings, fuel line and fuel gauge  in cap

 Aluminium propeller



Warning and protection:

 Low oil pressure warning (visual and audible)

 Safety Lanyard

 Start-in-gear protection

 Over-rev limiter

 Battery voltage warning (visual only)

 Overheat warning (visible and audible)

Specifications

Engine:                                                            3-Cylinder

Output:                                                           40hp (29.4kw)

Displacement:                                                866cc

Bore & Stroke                                                 70 x 75mm

Fuel Induction System                                   EFI

Starting                                                            Electric

Control Type                                                    Remote Control or Tiller Handle(Tiller Version)

Gear Shift                                                         F-N-R

Gear Ratio                                                        2.08:1

Transom Height                                               20'"

Weight (lightest configuration)                      95kg

Alternator Output                                           12V,21A

Fuel                                                                   Unleaded Gasoline (87 ocaine)

Engine Oil Type                                                AP1-SH,SJ,SL                                                                                  10W-30/40
