Tohatsu Motors - MFS6CD

MFS6CD



Fundamentals for user convenience and reliability:

 Through-the-prop exhaust for a quieter ride

 Thermostatically controlled cooling system for consistent engine  temperature

 Stainless steel water pump housing for outstanding durability

 High grade marine aluminium alloy that provides the ultimate  protection against corrosion

 Zinc coating on internal water passages for superior corrosion  resistance

 Internal 1.15ltr Plastic fuel tank with forward of cowl located fill  cap

 Aluminium propeller

Shallow water drive

Adjustable steering friction for reducing steering effort

Front shift control

Longer Tiller handle for ease of control


Protection:

 Low oil pressure indicator

 Safety lanyard (an essential protection feature standard on all  Tohatsu outboards)

 Start-in-gear protection for safer engine starting



* Certain models

** MFS6CD  includes an External Tank Connector installed on engine to allow user to use an optional external fuel tank



Engine:1-Cylinder

Displacement:123cc (7.5 cu.in.)

Bore & Stroke:59 x 45mm (2.32 x 1.77 in.)

Starting:Manual

Controls:Tiller Handle

Gear Shift:Forward - Neutral - Reverse

Gear Ratio:2.15: 1 (13:38)

Propeller Pitch Range:8"  (6"- 9" OPTIONAL)

Transom Height:15, 20

Fuel Mix:Unleaded Gasoline (87 Octane)

Oil Type:Refer Owners Manual

Fuel Tank:Internal 1.15 ltr

Weight (Min Version):26.1 kgs

RPM Range:

4,500 - 5,500
