Tohatsu Motors - MFS3.5B

Tohatsu 4 Stroke 3.5HP Outboard Motor
MFS3.5B



Easy operation and handling:

 Digital CD ignition system for easier starting, quicker throttle  response and smoother trolling

 Forward-neutral shifting with 360 steering.

 Easy to check oil gauge

 Convenient carrying handle

 Adjustable steering friction device for reduced effort

 Throttle grip control

 Fast idle choke system allowing easier manual choke operation



Fundamentals for user convenience and reliability:

Thermostatically controlled cooling system

Four point dampening system reduced vibration

High grade marine aluminium alloy provides protection against corrosion

Zinc coating on internal water passages for corrosion resistance

Built in 1.3 ltr tank



Protection:

Safety lanyard

Throttle grip control



Engine:                                                 1-Cylinder

Displacement:                                     86cc (5.25 cu. in.)

Bore & Stroke:                                      55 x 36mm (2.17 x 1.42 in.)

Starting:                                                Manual

Controls:                                              Tiller Handle

Gear Shift:                                            Forward - Neutral

Gear Ratio:                                           2.15: 1

Propeller Pitch Range:                       4.5 - 6

Transom Height:                                15,20

Fuel Mix:                                              Unleaded Gasoline (87 Octane)

Oil Type:                                              Refer Owners Manual

Fuel Tank:                                           1 ltr integral tank

Weight (Min Version):                       18.4 kgs

RPM Range:                                        5,000 - 6,000
