SEAFLOW 12V WATER PUMP RV SUPREME 113LPM 55PSI

Description

The Seaflow RV Supreme 12V water pump is a compact fresh water pressure pump designed for caravans, RVs, camper trailers, boats, motorhomes and off-grid vehicle water systems.

With an 11.3LPM flow rate and 55PSI pressure cut-off, this pump is suited to supplying taps, showers and general onboard water outlets where reliable 12V water pressure is required.

The automatic demand design uses a built-in pressure switch, allowing the pump to start when a tap is opened and stop when the tap is closed. Internal bypass technology helps reduce rapid cycling and provides smoother, quieter operation in typical RV water system use.

Product Details
Product: Seaflow 12V Water Pump RV Supreme 11.3LPM 55PSI
SKU: 940537
Voltage: 12V DC
Flow rate: 11.3 litres per minute / 3.0 GPM
Pressure cut-off: 55PSI / 3.8 bar
Operation: Automatic demand pressure pump
Connection size: 1/2" BSP
Maximum current: 6A
Priming capability: Up to 1.8m suction lift
Weight: Approximately 1.9kg
Common Uses
Caravan fresh water systems
RV and motorhome water supply
Camper trailer water systems
Off-grid vehicle builds
Boat and marine fresh water systems
Remote cabin or holding tank water systems
Key Features
12V fresh water pressure pump
11.3LPM flow rate for strong onboard water delivery
55PSI pressure cut-off
Automatic pressure switch operation
Self-priming design
Run-dry safe design
Internal bypass technology to help reduce cycling
Quiet operation for caravan, RV and motorhome use
Low power draw
Rubber mounting base to help reduce vibration
1/2" BSP inlet and outlet connections
Water System Benefits
Provides pressurised water from a holding tank system
Designed to start and stop automatically as outlets are opened and closed
Suitable for systems where an accumulator tank is not normally required
Helps provide consistent water pressure for taps and showers
Compact design makes it suitable for tight installation spaces
Installation Notes
Designed for 12V DC systems only.
Correct polarity, fuse protection and wiring size should be confirmed before installation.
The pump should be mounted securely to reduce vibration and movement.
A strainer or filter should be used before the pump to help protect it from debris in the water supply.
Final suitability depends on the water tank position, plumbing layout, number of outlets and required water flow.

Important: This is a 12V water pressure pump for RV, caravan, camper, marine and similar fresh water systems. Confirm voltage, plumbing connection size, mounting space and water system requirements before ordering.
