Alpine 18.6F - Full Off Road

ALPINE 18.6F
FULL OFF ROAD

The 18.6ft single axel Alpine is a compact off road family bunk van! It’s got everything you would find on a larger van and much more! With suspension options ranging from 2.9t  on a single axle you can say goodbye to worrying about what extras to leave off your custom build.

CHASSIS AND RUNNING GEAR
Chassis : Supergal Australian RHS Steel Chassis
Hitch: Full Articulated Off-Road Tow Hitch
A - Frame : 6” Extended A Frame with RHS Australian made Steel
Deck: 6” Chassis – 6' deck 2’raiser” Chassis, RHS Australian Steel
Suspension: 2.9 t single axel ox trek suspension
Shockers : Pedder’s Suspension Trak Ryder Dual Shock Absorbers & Spring
Bumper: 3 Arm Heavy Duty Steel Bumper (Rear)
Jerry Can Holders: 2 x Black Rear Mounted
Stabilising Legs: 4 x Heavy Duty Stabilising Corner Legs
Spare Wheel: 1 x 16" MPC Mainline Black / White Writing Out (Rear Bumper)
Wheels: 2x 265/75/R16 A/T Tyres
Jockey Wheel: 8" Alko Heavy Duty Centre Mounted Jockey Wheel
Brakes: 12" Electric
Battery Box : Dual Heavy Duty Steel Box
Jack Corner Supports: 4
Jack: Kojack

EXTERNAL BUILD
Walls Framing : 2x1 Meranti Timber 42mmx19mm Stapled Glued with 3ml White Plywood
Furniture : Meranti Timber Stabled Glued screwed with 3ml White Stipple Plywood
Floor - Marine Grade Plywood: One Piece (Structural Grade)
Roof : 2x 1 42mmx19mm Meranti Timber Double installation 6ml & 12ml lightweight plywood
Hard Wearing Vinyl Floor: 1x piece Vinyl Floor glued
Building : Furniture front, back, roof all Screwed plus Bolted
Frame: Meranti Timber
Insulation: Styrene (Walls & Roof)

EXTERNAL FEATURES
Cladding : Corrugated High-Profile Aluminium
x Plate : Side /back/front x plate
Cladding Front : Flat Aluminium Composite
Cladding Back : Flat Aluminium Composite
Cladding Roof: Fibreglass Skin
Sway Control : Alko Sway control
Window - Double Glazed: Dometic Double Glazed
Entry Door : Black Dust Proof Door (Tri-Lock)
Speakers (External): 2 x Black Internal 6" Outdoor Marine Speaker
Toolbox: With Generator Slide-Out (Off-Side)
Awning: Manual Charcoal Aussie Traveller Roll-Out Awning
Tunnel Boot: 2 x Extra Large Openings - Vinyl Floor/White Plywood Custom Aluminium Doors
Picnic Table: Drop Down Metal Picnic Table
Gas Bottles: 2 x 9kg (Silver Mounted on A-Frame)
Step: Single Pull Out (Manual)
Work Lights : 2x Stedi Work lights on front and rear
External Shower: 1x Hot/Cold Water Marked Black
Camera : Rear Safety Dave Camera
Coaxial input : 240V And Coaxial Offside Inputs
LED External Lights: 4 x Black Aluminium (2 x Below Awning, 1 x Offside, 1 x Over Tunnel Boot)
External Tv Hatch: 1 x External Tv Hatch with Digital Coaxial, 12v, 2 x 240V and 1 x USB Connection Points
Water Tank Protector: Galvanised
Front Stone Mesh Guard: Front Stone Mesh Guard w/ mudflaps Everest Logo
Mudflaps: Rear (Black) w/ mudflaps Everest Logo
Grab Handles: 4 x 300mm Black (2x Front & 2x Back)

INTERIOR BUILD
Hard Wearing Vinyl Floor:
Lightweight Plywood acrylic Doors:
Lightweight Plywood Laminate Benchtops:
Recessed Covered Cooktop:
Double Gas Struts To All Overhead Cupboard:
Laminate Splashbacks:

INTERIOR APPLIANCES
Air conditioner: Ibis 4
N3141-A 141Ltr 3-Way Automatic: N3141-A 141Ltr 3-Way Automatic
Rangehood: Sphere Recessed
Hot Water System: GEHWB Swift 28Ltr Gas/Electric
Microwave: Sphere 25Ltr
TV : 24’ smart tv dvd combo
Stereo: Furoin Bluetooth
Washing Machine: In robe
Toilet: Saneo Ceramic Bowl
Fridge/Freezer: N3141‑A 141Ltr 3‑Way Automatic

INTERNAL FURNITURE
Bed - Queen Island : East west
Mattress - Innerspring Pillow-Top: Queen Size
Bunk Beds: 2 or 3 x Bunks
Bunk Ladder: Built In
Bunk Curtains: 2 or 3 X Each Bunk
Tic Cushion : Table Tic Cushion

ELECTRICAL
Antenna: AntennaTek LPDA200
Battery Management System: BMPRO 35HA Battery Management System (Lithium Ready)
BMPRO: Trek Digital Display Trek Digital Display " (All-In-One Water, Battery, Pump and Mains Controller)"
Batteries : 2 x 100amp Lithium Lab Batteries
Solar Panels: 2 X 210-Watt Solar Panels
Reading Lamps w USB: Dual Colour RL Blue/White USB (2 or 3 x Bunks, 2 x Bedhead Sides, 2 x Near Lounge)
LED Strip Light (Internal): White Strip Light in Aluminium Track Under OHC (Master, Lounge & Kitchen)
LED Strip Light (Internal): Blue Strip Light (Step)
RCD/MCB Enclosure : 2-Way White Housing
RCD/MCB Circuit Breaker : 16A White (Internal)
Anderson Plug: 50A Grey Anderson Plug
Pin Plug: 12 Pin (Black)
Entry Handle Light: Blue Lit Bubble (Black)
Waterproof Lights: 2 x Waterproof LED Shower Lamp White with Switch (1 x Shower x 1 x Tunnel Boot)
Tail Lights: 6 x Dynamic Combination 130mm
Work Lights : 2x Stedi Work lights on front and rear
LED External Lights: 4 x Black Aluminium (2 x Below Awning, 1 x Off Side, 1 x Over Tunnel Boot)
Downlights : 75mm Round (Silver)
Touch Light: Interior Strip Light (Below OHC in Ensuite & Sink)
TV Points Standard: 2 x Internal, 1 x External
TV Hatch (External): Standard Points
Speakers (External): 2 x Black Internal 6" Outdoor Marine Speaker
Speakers (Internal): 2 x White Internal 5" Ceiling Speaker

PLUMBING
Gas Bayonet: 1 x Front Gas Bayonet awning side
GAS BOTTLES : 2 x 9Kg Gas Bottles
Water Tank Probes: 3 x 7.5m Dippers
Water Tank Gauge: Trek Digital Display
Water Tanks: 2 x 110L
Grey Water Tank: 1 x 95Ltr
Pump: 1 x Shurflo
Kitchen Tap: 340mm Black Kitchen/Bathroom Tap
Bathroom Tap: Basin Mixer Matt Black
Sink (Kitchen): BLACK GRANITE bowl
Ceramic Sink (Ensuite): Above Counter Basin BLACK OR WHITE
Gas Bayonet: Front Adjacent To Front Tunnel Boot
External Shower: 1x Hot/Cold Water Marked Black
Tap on Chassis : On A-Frame with Checker plate protection
28L Stainless Steel Swift Gas and Electric Hot Water System:
Plumping underbody Protection - Plumbing and Pipe Protection on Exposed Underneath PVC Pipework:
Large One-Piece Fibreglass Shower with fibreglass roof with Extractor Fan:
