HS2250P 2 X 250W POWER AMP - MINI DSP RS232-USB

AUSTRALIAN MONITOR HS2250P 2 X 250W POWER AMPLIFIER USB/RS232 CONTROL WITH MINI DSP

The HSP series is Australian Monitor's next generation ofcontrollable Class D power amplifiers, delivering high quality audio reinforcement with the power you need in the following options

Single channel 120W or 250W, Dual channel 120W or 250Wand Quad channel 120W or 250W.

Australian Monitors new power amplifiers are fully featured, including an efficient Class D amplifier, USB and RS232 control and a mini DSP featuring volume control, mute,compressor/limiter, filter and input channel selection.

The HSP series power amplifiers give the AV contractor a reliable amplifier for applications that are price sensitiveyet still require high quality commercial sound reinforcement and control.

KEY FEATURES
2 x 250W power amplifier

4 ohm, 70V and 100V output options

Class D topology

Programmable via PC UI application

USB and RS232 control

Mini DSP - Volume controls, input / output routing, high and low pass filtering, compressor / limiter, pink noise / sine wave generator, muting and inversion

Mute control via contact

Standby control via contact
Fault status via contact

CLASS - D - AMPLIFIER

The HSP amplifiers use an efficient Class-D amplifier topology allowing a greater power density with a much lower weight.

All amplifier channels offer 100V, 70V and 4? output options so you can choose the output configuration to match your application.



PC CONTROL APPLICATION

Take control of your amplifier using the HSP Control Software.

The control software allows you to modify signal routing, DSP settings, channel naming, retrieve status information and more.
Download it now from the download section of this page and see what the HSP amplfier can do.



INTEGRATED MINI DSP

The HSP amplifiers include a mini DSP engine with the following features,

Input/Output Router

High, Low Pass Filters

Compressor / limiter

Mute

Inversion



3RD PARTY CONTROL

Take further control of the HSP amplifiers with 3rd partysystem support over USB or RS232.
Enter "Developer Mode" in the PC application to easily seethe commands being sent and received from the amplifier.
The HSP control protocol can be found in the manual.



SPECIFICATIONS
Output Power per Channel 250W Frequency Response 100Hz - 16kHz
Output Channels 2 THD N
Output Mode 4 Ohm-70V-100V Signal to Noise Ratio > 97dB
Input Voltage 100-240Vac 50-60Hz Input Sensitivity 1Vrms
Mounting 1RU Cooling Fan-assisted
Warranty 5 years
Product Dimensions
(W x D x H) 483mm x 325mm x 44.5mm Shipping Dimensions
(W x D x H) 525mm x 425mm x 120mm
Net Weight 9.0 Kg Shipping Weight 11.2 Kg
GTIN EAN 9323383019935
