VXC4W 4" CEILING MOUNT SPEAKERS BASS REFLEX WHITE FULL RANGE

Yamaha designed the new VXC speakers to accommodate a growing list of applications in the installation market. While these speakers deliver quintessential Yamaha sound quality, they have also been carefully designed for safe andeasy installation. Featuring a simple ceiling mount option, this 4" full range ceiling speaker are available in either black or white, or can be painted to match the interior of any application. CEILING SPEAKERS FOR ANY APPLICATION The VXC Series offers three different woofer sizes, allowing you to choose the speaker that is most suitable foryour venue. Each model has an internal transformer that allows both high and low-impedance drive with just a single speaker, simply by switching the tap on the baffle. Since a single speaker can be used for both operations, inventory control is simplified, and you can easily adapt your system to any changes. SAFE, SEAMLESS INSTALLATION Series speakers' Anti-Drop tab allows them to be mounted temporarily in the ceiling, freeing your hands for better safety and ease of installation. An attached, flexible carrying band also makes the speakers very portable, allowing you to carry multiple speakers at once safely. Additionally, VXC Series speakers also come complete with O-rings and tile rails for a safer, smoother installation. PURSUING THE BEST SOUND FOR INSTALLATION We developed the VXC Series speakers to address a demand in the installation market for speakers capable of providing superb music reproduction as well as crystal clearannouncements for public address applications. The VXC4 features a newly customized transducer withlarge, powerful magnetic circuits that increase driving and braking force substantially, as well as a dedicated tweeter diaphragm and speaker cone paper made from a carefully-created blend of materials that help optimize sound reproduction. Cabinets are built tough to meet the demands of a wide variety of commercial environments, constructed from a carefully selected plastic with just the right tensile strength, and designed with optimized bass-reflex tuning to offer a firm, tight low-end. From the networking components and the materials usedfor wiring and soldering, right down to the optimal placement of acoustic absorption material, a great deal of attention has been paid to even the smallest details of the series' design. SPEAKER DESIGN Several aspects of these speakers' design reflect a strong emphasis on functionality as well as the aesthetic features of their construction - effectively enhancing soundquality and speaker performance without disturbing the interior decor of the installation. This concept is evident in the hexagonal design featured on the grille of both series' speakers that actually improves sound clarity by raising the aperture ratio. Even the innovative design of the VXC's tweeter improves sound clarity by providing unrestricted woofer movement. PAINTABLE SPEAKERS FOR YOUR UNIQUE ROOM DESIGN VXC series comes with paintable speaker grilles. Not only filling your room with premium sound, VXC series enhances the design of interior by painting its grille in any color you like such as light color, deep color, or the best matching color to your decors. VXS/VXC Series Painting Guide   SPECIFICATIONS VXC4 General specifications VXC4W Speaker type Full-range, Bass-reflex Frequency range (-10dB) 80Hz - 20kHz (Half-space:2p) Nominal coverage 130°Conical (Half-space:2p) Components LF-HF 4" full-range Power rating NOISE 30W PGM 60W PEAK 120W Nominal impedance 8O Transformer taps 100V 30W (330O), 15W (670O), 7.5W (1.3kO) 70V 30W (170O), 15W (330O), 7.5W (670O), 3.8W (1.3kO) SPL Sensitivity (1W; 1m on axis) 87dB SPL (Half-space:2p) Peak (Calculated) 108dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression) I/O connectors 1 x Euroblock (4P) : (Input: / -, Loop Thru: / -) Finish VXC4: Black / VXC4W: White Dimensions Diameter 225mm (8.9") D 195mm (7.7") Net weight 2.6kg (5.7lbs) Cutout size Ø186 mm (Ø7-5/16") Required ceiling board thickness 5 mm ? 35 mm Accessories O-ring, Tile Rail, Cutout Template Packaging Packaged in pairs Certificate UL1480, UL2043, NFPA70, CE, EAC, RoHS EN54-24 compliance - Waterproof -     VXC4/VXC4W Owner's Manual PDF file Weight: 9.00 kg Barcode Number: 4957812523615
