EQ5-S8 5.25" CLOTH SPEAKER EQ5S8 MIDBASS 65W 8OHM SEALED BASKET

FEATURES Earthquake sealed basket speakers, ideal replacement for your speaker for audio needs. The Earthquake EQ line of Maximum Musical Output drivers are specifically designed to provide smooth, low-distortion mid-range/mid-bass output for the highest quality sound reinforcement applications. Because of their relatively highresonance and very low Qts values, the EQ line can be mounted in small enclosures while maintaining a smooth, peak-free response. High efficiency / sensitivity Multi roll cloth surround New longer lasting, low mass cone Stamped steel basket with jet-black finish Enhanced sound quality Heavy duty ferrite magnets Edge-wound aluminum bobbin voice coils Low harmonic distortion Max output @ low wattage Sealed Basket Not Vented T-Yoke Bumped Back Basket SPECIFICATION Size: 5" (127mm) Midbass Resonance: 503Hz /- 15% Frequency Response: 300Hz - 14kHz Max Power Rating: 100W Impedance: 8Ω Sensitivity: 96dB Magnet Wieght: 30oz. (0,85 kg) EQ5-S8 Manual PDF file Weight: 1.32 kg Barcode Number: 168975910486
