PRO1326 COMPACT IR REPEATER KIT FOXTEL IQ COMPATIBLE

Hide your AV equipment in a cupboard or rack without losing the ability to control them with their Remote Controls. Installing the Compact IR Repeater kit is quick and simple, and expandable offering extra output ports for more emitters/equipment! FEATURES Four amplified emitter output connections convenient IR confirmation LED Power indication LED Compact size for mounting near audio equipment IR receiver and emitters supplied Compatible with Foxtel IQ2 IN THE BOX 1x Compact IR Repeater Box 1x IR Receiver (3.5mm Stereo plug) 2x Dual IR Emitters (3.5mm Mono plug) 1x Power Adapter (5VDC / 500mA) 2x Mounting Screws SPECIFICATIONS Repeater Box Receive/Transmit Frequency 38kHz ~ 56kHz Power 5VDC / 500mA Dimensions 104x32x17mm Weight 25g IR Receiver Range 40ft @ 38kHz 25ft @ 56kHz Connector 3.5mm stereo plug   Tip: Signal Ring: V Sleeve: Gnd Cable Length 3metres Dimensions 20x9.4x7mm (excl cable) Weight 21g IR Emitter Emitters/LEDs 2x (Dual) IR Wavelength 940nm Cable Length 3metres Connector 3.5mm mono plug Tip: Signal Sleeve: Gnd FAQS Can I use the PRO1326 with other Pro2 accessorieslike IR hubs, IR targets and IR wall plates? The accessories are designed to be compatible with the PRO1187 IR block but not the PRO1326. Since the Vcc output voltage from IR Receiver socket (on thePRO1326) is 5 volts (not 12 volts like the PRO1183) so you can?t connect the output of the PRO1326 to many of the otherPro2 IR accessories. Why the IR confirmation blue LED stays on? Please make sure IR target has been plugged in. Once plugged in, the IR confirmatino light will be off and only blinks when it receives IR signal. Weight: 0.2350 kg Barcode Number: 9328202015204
