ATSP38 38DB GAIN CATV AMPLIFIER 107DBAV OUTPUT FOX APP F31092

ATSP38 38DB GAIN CATV AMPLIFIER FOXTEL: F31092 Features: Attenuation and equalisation adjustable Attenuation and equalisation pluggable with jumpers Solid all die-cast housing Test ports at the input and at the output Specifications: Forward Path Frequency range 85-1006MHz Gain 38dB Attenuation adjustable 0-15dB Attenuation pluggable with jumpers 0, 2, 4, 6 dB Equalisation adjustable 0-15dB Equalisation pluggable with jumpers 0, 2, 4, 6 dB Return Loss: 18dB Noise figure: 5.5dB Maximum output level CSO/CTB 107 dB V Return Path Frequency range: 5-65MHz Gain: 30dB Attenuation adjustable: 0-15dB Attenuation pluggable with jumpers 0, 6 dB Equalisation pluggable with jumpers 0, 3, 6, 9 dB Noise figure: 7dB Test port Input: - 20dB 2.5dB, Output: - 20dB 1.0dB Power supply: 100-240V AC / 50-60Hz Power consumption: 10W Power indicator LED Ambient temperature range: -20°C to 50°C Earth terminal: Yes Dimensions: 195x90x55mm Weight: 0.9540 kg Barcode Number: 7611682003758
