A3506D TOA 60W 5 INPUT MIXER AMP 2 ZONE -100V - 4-16 OHM

TOA A-3506D 2 ZONE 60W MIXER AMPLIFIER The A-3500D series PA amplifiers are available in 60w / 120w / 240w / and 480w models all come with emergency and priority paging and remote zone control. They are equipped with 4 microphone inputs and 1 auxiliary input and 2-channel zone selector, and are 100v and 4-16 ohm output The A-3506D is a class D mixer amplifierwith 60 watts output. It comes with emergency and priority paging, is equipped with 3 MIC/LINE inputs, 1 MIC input, 1 AUX input can be alsoused for music source. With 2-channel speaker zone selectors it is ideal for paging announcements and background music applications in retail shops, schools, offices and production facilities.- 120 W Class D mixer amplifier for high and low impedance speakers KEY FEATURES 5 Inputs: 1 Mic, 1 AUX, 3 MIC/AUX (selectable) , 2x Phantom power 2 Zone speaker selector (high impedance only) 2 Line out, 1 Rec out 2 Zone control inputs / outputs 1 Emergency output   TOA A3506D SPECIFICATIONS A-3506D Power source 100 - 240 V AC, 50 / 60 Hz Rated output 60 W Frequency response 50 Hz - 20 kHz (±3 dB (1/8 rated output) Distortion ≤ 1 % (at 1 kHz, rated power) Power consumption 96 W (at rated output), 40 W (EN62368-1) Speaker output direct, zones 1 & 2 Amplifier Class D S/N ratio 88 dB (A-weighted) Connectable microphones 3 Inputs INPUT 1, 2: –60 dB* (MIC)/–20 dB* (LINE) selectable, 600 Ω, electronically-balanced, removable terminal block (3.81 mm, 5 pins)/Ø6.3 mm phone jack (2P) INPUT 3: –60 dB*, 600 Ω, electronically-balanced, Ø6.3 mm phone jack INPUT 4: –60 dB* (MIC)/–20 dB* (LINE)selectable, 600 Ω, electronically-balanced, Ø6.3 mm phone jack (2P) INPUT 5: –20 dB*, 10 kΩ, unbalanced, RCA pin jack x 2 PWR AMP:IN: 0 dB*, 600 Ω, unbalanced, RCA pin jack Control input 2 channels, no-voltage make contact input, openvoltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (3.81 mm, 5 pins); ZONE control: No-voltage make contact input, openvoltage: 35 V DC or less, short-circuit current: 10 mA or less, removable terminal block (3.81 mm, 4 pins) Outputs REC, LINE 1/1: 0 dBV, 600 ohms, unbalanced, RCApin jack SPEAKER direct, zones 1 and 2: 8-16 ohms in totalor 100 V Control output Power remote, emergency, zone control: Open collector output, withstand voltage: 30 V DC or less, control current: 25 mA or less, removable terminal block (3.50 mm, 4 pins) Operating humidity 85%RH or less (no condensation) Operating temperature –10 to 40 °C Finish ABS resin, Steel plate, paint, black Dimensions 420 x 96 x 313 mm (W x H x D) Weight 4.9 kg Accessory (included) AC Power cord (Euro) Â
