RG11QDR-100M RG11 QUAD SHIELD COAX CABLE 100M ROLL 75OHM DOSS

Cable construction (inner- to outer-most): Core: 14 AWG / Ø1.63mm CCS (Copper Coated Steel) 21% DC Resistance: 11Ω / 1000ft. at 20°C Dielectric Foam PE: Ø7.11mm Shielding: Bonded Aluminium Foil Braid Aluminium Shield: 96x Ø0.16mm, 60% Coverage Non-bonded Aluminium Foil Braid Aluminium Shield: 64x Ø0.16mm, 40% Coverage Shield DC Resitance: 6.9Ω / 1000ft. at 20°C PVC Jacket: Ø10.3mm Colour: Black Operating temperature range: -20 ~ 60°C Return loss: 15dB Max (100% swept tested) Impedance: 75.0Ω ± 3Ω Attenuation: 0.20dB/100ft @ 1MHz 0.50dB/100ft @ 10MHz 0.95dB/100ft @ 50MHz 1.25dB/100ft @ 100MHz 1.75dB/100ft @ 200MHz 2.45dB/100ft @ 400MHz 3.35dB/100ft @ 700MHz 3.8dB/100ft @ 900MHz 4.00dB/100ft @ 1000MHz 4.40dB/100ft @ 1200MHz 4.80dB/100ft @ 1450MHz 5.30dB/100ft @ 1800MHz 5.80dB/100ft @ 2200MHz Barcode Number: 9328202021045
