DBPC946B DUAL BEAM PHOTOELECTRIC SENSOR DIGITAL PULSE BEAM

Secure your land and get alerted when anything passes theline! With this Dual-Beam Photoelectric Sensor you will be able to set up a security line and hear a warning sound if any movements are detected. Capable for both indoor and outdoor use. Now with digital display! FEATURES Wired/BUS compatible, 8 digital frequency range. Dynamic frequency analysis Intelligent alarm linkage links alarm to your existingsecurity system Tamper, fault and alarm contact outputs Powerful sensor signal transmission with anti-fog design for the sensors. Adopt coaxial aspherical dual optical focusing lens. Digital display BUS address, signal strength and working frequency. Blocking time adjustment for specific target movement rate detection. Protection range up to 90-180m (Indoor)/ 30-60m (Outdoor) Comes with post mounting kit(Diameter 25 to 40mm approx): Screws, mounting plate and mounting saddle. SPECIFICATIONS Model DBPC946B Alert Distance Outdoor 60m Alert Distance Indoor 180m Number Of Beams 2 Detection Mode 2 Beams blocked simultaneous Optical Source Infrared digital pulse beam Response Time 50-240ms (Adjustable without degree) Power Supply DC12-24V 15W Alarm Output Relay contact output NO. NC contact rating AC/DC 30V30mA Max Trouble Output Relay contact output NC contact rating AC/DC 30V 30mA Max Tamper Output Relay contact output NC contact rating DC24V 0.5A Max Operation Temperature −25°C-55°C  Operation Humidity 5%-95% Optical axis(Horizontal) 180°(Default position±90°) Optical axis (Vertical) 20°(Default position±10°) Material P C resin Net Weight 430g (Receiver Transmitter) Gross Weight 790g Manual PDF file Weight: 1.05 kg Barcode Number: 9328202026125
