PK4918 5V USB KEYSTONE INSERT SUITS MWI13KS MW13FR

FEATURES Single output current up to 2.8A, which suits the latest tablet power consumption; Can be daisy-chained to the next PK4918 USB socket, depends on the power input, up to 12x USB; Snap and fits in all keystone wall plates, or be part of the PRO2 modular wall plate range; Synchronous rectification and high efficiency, up to 92% from 12V to 5V 1A; 400W TVS diode to protect your USB device from the 5V output; Input with reverse polarity protection diode, protect your device from damaging when the input connection is incorrect; Using the latest USB identification circuit, perfectlycompatible with smartphones and tablets; Output voltage indicator (Blue); Provides complete fault protection such as input under-voltage lockout, output short circuit protection, over current protection, and thermal shutdown; Perfect for equipment racks, Conference rooms, A V Systems, Planes, Yachts, RV’s, Busses, Bars, Gyms; Can be powered by any power wire or UTP cable fromDC 6-24V. SPECIFICATIONS: Dimensions:41L x 17W x 21H mm Main chip type: Non-isolated synchronous rectification Input voltage: DC 6~24V Output voltage: 5V Output current: 2.8A Max Conversion efficiency: 12V to 5V 1A up to 92% Switch frequency: 410 kHz Output ripple: 10mV around (12V to 5V @2A) Static current: 0.5 mA CONNECTION DIAGRAM FAQ Q:What is the maximum number of devices that can be daisy-chained together? A:It depends on the power input voltage. Please refer to the following table for the suggested estimated number of this product that is daisy-chained. Power input source The estimated maximum number of this product 12V/1A 3 12V/2A 6 24V/1A 6 24V/2A 12   Manual PDF file Daisychain PDF file Weight: 0.0280 kg Barcode Number: 9328202020697
