Earthmoving Machinery
Lely MultiDisc XL Vario
Contact for price
Verified seller
Description
Standard specification
Special benefits
.
Further explanation accessories
- Integrated subsoiler tines with hydraulic stone protection per leg
- 2 Rows of large discs made out of hardened steel ? 560 mm
- Replaceable tine points, shins and wings; 6 models of wings available
- Heavy bearings with overdimensioned wheel hubs, low maintenance
- Torsion bar suspension by means of triangular rubbers for a maximum freedom of movement of every discseparately
- Stable, powder coated frame with robust headstock, prepared for the assembly of a Tulip airseeder
- Up to 350 XL Vario (-S): linkage cat. III
- Up from 400 XL Vario (-S): linkage cat. III/IV
- Depth control by means of the floating system with crumbler roller ? 520 mm
Special benefits
- Tillage of the upper soil layer and deep cultivation in one pass
- Extra strong box section on which the tine holders are fixated. By folding the legs you can turn the machineinto a normal disc harrow
- The tines are individually adjustable in both height and width. So it’s possible to position a tine right in thewheel track of the tractor and to set it a little deeper than the other tines. Or just mount 2 tines and use themonly in the tram lines.
- Depth of tines: from 2 up to 24 cm under the discs. So both shallow and deep tine settings are possible.
- Non-stop operation: if necessary the tines can break out upwards. The discs and roller continue to follow theground. Afterwards the leg is automatically pushed back into the soil. The sensitivity is adjustable.
- Hardened steel discs, solid side fastening with 5 bolts 10.9, simply accessible.
- The aggressive action of the serrated discs and the extra large distance between the rows of discs give an idealmulching and mixing result of crop residue or green cover crops.
- Extra protected sealing of the bearings; lubricator chamber provided with a large quantity grease; hot forgedhub.
.
Further explanation accessories
- The packer roller ? 500 mm and the packer roller ? 600 mm are in combination with this heavy machine onlysuited for heavy, non sticky soil.
- Hydraulic roller adjustment: two cylinders who fold up the roller so that the point of gravity comes closer to thetractor
- Straw harrow: is mounted behind the last row of discs and assures an improved coverage of crop residue. Theheight and angle are adjustable.
- Soil deflector plate right: a ground following side plate which keeps the soil stream inside the working width.Transport width increases with 7 cm.
- Central greasing: all grease nipples are brought to one point.
- Oil bath bearing: maintenance free bearings in an oil filled housing.
