Promax 680 Blue Retro Graphic Welding Helmet Weldclass WC-05345

PROMAX 680 BLUE RETRO GRAPHIC WELDING HELMET WELDCLASS WC-05345

FEATURES:

7-year Warranty*
Enormous 95cm2 viewing area
'Landscape' format (116mm wide x 82mm high) window/screen for a wider & more natural field of view
Ultra-Crisp V1 (1/1/1/1) rated optics with enhanced color recognition
Illuminated digital LCD/controls for superior visibility (auto dims when adjustments are not being made)
Advanced digital controls with memory, cut mode, gradient & other functions
External controls for shade adjustment & all modes: allows for instant & easy adjustment without removing or lifting the helmet
Auto Controls: Option of Manual (user adjusts), or Auto shade / Sensitivity / Delay adjustment (helmets adjust settings automatically depending on arc intensity)
Super-comfortable, wrap-a-round headgear with a molded rear pressure pad
Lightweight (620g), up to 10% lighter than other digital wide-view helmets

APPLICATION INFO:

MIG welding
Stick welding
TIG welding down to 5 amps
Grinding
Plasma Cutting
Oxy Cutting, Brazing, Heating
Gouging

FUNCTIONS:

Shade adjustment: Auto (shade level adjusts automatically depending on arc intensity) or Manual (user adjusts), adjust in increments of +/- 0.5 via external or internal controls
Shade Deviation: When using Auto shade, +/- deviation (fine adjustment) can be adjusted in 0.1 increments to up +2.0/-2.0
Welding mode: Variable shade 9-14
Cut mode: Variable shade 4-8
Grind mode: Locks lens to light mode (shade 3), activate on/off via external button or internal controls
Shade Lock: Switches off auto-darkening function & locks lens to a selected shade level (4-13), ideal for oxy cutting & similar processes where conditions may not be ideal for normal auto-darkening function
Memory: Save up to 9 favorite settings (recalls shade, sensitivity & delay settings), with an instant save function on external controls
Delay (switching time from dark back to light after welding stops): Auto or Manual 0.1-1.0s
Gradient Mode: Gradual return (slope down) from dark to light, mirrors cooling of the weld pool to reduce eye strain
Sensitivity: Auto or Manual 0-9 settings
Tack Mode: Returns to shade 5 (instead of shade 3) between welds to reduce fatigue

FEATURES:

High-Impact tested and compliant with Australian standard AS/NZS 1337.1
Auto-darkening lens complies with AS/NZS 1338.1
Easy cover lens replacement
Magnification lens holder - takes standard magnification lenses
Reliable Power Source: Replaceable battery plus solar assist, efficient electronics for low power consumption
Full-Laminate Lens Construction: Each layer in the electronic lens assembly is firmly laminated for superior optical quality and long service life. This is in contrast to cheaper lenses which are simply glued on the edge and, over time, are prone to contamination and failure.
Lightweight, Durable, and Shock Resistant shell
Weight: 620g
Auto-on & Auto-off = No buttons to press, Hassle-Free operation



Part Number/SKU: WC-05345

* Product Images are for illustration purposes only, unless otherwise specified colour may be different.
