Ortofon Hi-Fi 20 Replacement Stylus

Replacement stylus for Ortofon 20 series cartridges

Technical data |
---|---
Frequency range | 20-27,000 Hz
Frequency response | 20-20,000 Hz + 2 / - 3 dB
Tracking ability at 315Hz at recommended tracking force | 80 µm
Compliance, dynamic, lateral | 25 µm/mN
Stylus type | Nude Elliptical
Stylus tip radius | r/R 8/18 µm
Equivalent stylus tip mass | 0.4 mg
Tracking force range | 1.25-1.75 g (12.5-17.5 mN)
Tracking force (recommended) | 1.5 g (15 mN)
Tracking angle | 20°
Stylus colour | Black

Recommended for the following cartridges

*reprint form manufacturers website.Variant: Default Title
