Arcam AV41 8K AV Processor

Meet the Arcam AV41 8K AV Processor

Rich Musicality + Immersive Sound = Stunning Realism

The AV41 is a high-performance, audio/visual processor that delivers stunning realism for the ultimate home cinema experience. With native 16-channel decoding of immersive audio from Dolby Atmos, DTS:X and Auro-3D, the AV41 can deliver incredible theatre experiences in partnership with Arcam power amplifers.

The Arcam AV41 is designed with a passion for music and movies, bringing both to life with high fidelity and dynamics. The AV41 boasts XLR balanced outputs for all 16 channels to deliver the highest quality analogue connection to power amplifiers.

The performance and musicality can be assured with Dirac Live® room optimisation included, and accessed instantly with integrated streaming using Apple®Airplay2, Google Chromecast®, Bluetooth with aptX®HD, Spotify Connect, Tidal Connect and UPnP with the MusicLife app.

Dirac Live® Bass Control aggregates measurement and location data from each subwoofer as well as the main speakers to determine how a system’s bass is distributed throughout the room.

Product Features
16 Channels of Dolby Atmos, DTS:X & AURO-3D decoding
7 HDMI inputs, 3 HDMI outputs inc Zone 2, eARC compatible
HDMI 2.1 with HDCP2.3
All inputs support 8K@60fps and 4K@120fps
Supports Dolby Vision, HDR10+, HDR10 and HLG
Includes Dirac Live® room correction
Ready for Dirac Live Bass Control*
Dual ESS 9026PRO audiophile DACs with ESS reference voltage regulators
16 transformerless balanced XLR output channels
Pairs with PA720, PA240 & PA410 power amplifiers
Wi-Fi / Ethernet, RS232 and IR control
Google Chromecast® built-in for streaming audio
Apple® AirPlay 2
Bluetooth aptX®HD
Free MusicLife iOS and Android UPnP app
Roon Ready and supports MQA
Technical Specifications

STEREO LINE INPUTS

Maximum Output
4.5 Vrms

Nominal Sensitivity
1 V, 2 V, 4 V (User Adjustable)

Input Impedance
47 kΩ

Frequency Response
20 Hz — 20 kHz ± 0.1 dB

PREAMPLIFIER OUTPUTS

Nominal Output Level (Single-Ended / Balanced)
1 Vrms / 2 Vrms

Out Impedance
560 kΩ

THD+N (20 Hz — 20 kHz)
-100 dB

HEADPHONE OUTPUT

Maximum output level into 32 Ω
35 Vrms

Out Impedance
GENERAL

Mains voltage
110–120 V or 220–240 V, 50–60 Hz

Power consumption (maximum)
50 W (Thermal Dissipation Approx. 170 BTU/Hour)

Power consumption (Idle, Typical)
50 W (Thermal Dissipation Approx. 170 BTU/Hour)

Power consumption (Standby)
Dimensions W x D x H (Including Speaker Terminals & Feet)
433 x 425 x 171 mm

Weight (net)
10.6 kg

Weight (packed)
13.9 kg

Supplied accessories

Mains lead
Remote control with 2 x AAA batteries
Manual
DAB/FM Aerial
3 x Wi-Fi / Bluetooth Antennas
Calibration Microphone
USB Cable

Dirac Live® Bass Control
Dirac Live® Bass Control is available at an additional cost via the Dirac website: https://www.dirac.com/online-store/arcam-av41/



*This information has been obtained from Manufacturers website. We advise that Features, Specifications & Price are subject change from Manufacturer without notice.

E&OE
