FBR46ND24 24V DC 1A MICRO MINI RELAY DOUBLE POLE DOUBLE THROW

Microminiature low profilerelays occupy only one-half the volume and three-forths ofthe mounting area of conventional relays. - Size: 9.9 x 8 x 16mm (WHD). - Low Power dissipation Built-in highly effective permanent magnet, gives a pickup power dissipation of 85mW. (Rated power dissipation is 150mW). - High withstand voltage design Dielectric withstand voltage between the coil and the contact >1000V AC, and surge voltage resistance >1500V. - Formed terminals available for temporary mounting Unique formed terminals allows the relays to be mounted temporarily on the PC board. - Nominal Coil Voltage: 24V DC - Coil Resistance (± 10% @ 20°C): 2880 - Coil Current (at rated voltage): 6mA - Rated Power Dissipation: 200mW - Contact Arrangement: DPDT (2 Form C) - Contact Shape: Bifurcated Contact - Contact Material: Gold-overlay silver - Contact Rating: 24V DC 1A/120V AC 0.3A - Maximum Carrying Current: 1A - Max Switching Voltage/Power: 1 Weight: 0.0010 kg
