Meet  the DMS-650 Network Streamer

Breathtaking Sound, Seamless Connectivity

Experience the unparalleled versatility and sonic excellence of the entire DMS range a meticulously crafted family of products designed to elevate your audio experience to new heights. Engineered as a unified platform, each DMS model boasts an extensive array of features, playback capabilities, and user-friendly interfaces, ensuring a seamless experience across the board.

As the entry point of this lineup, the DMS-650 sets a new standard for excellence with its extraordinary sound signature characterized by full-bodied richness, natural midrange, and silky-smooth highs. Unlike other components, the DMS-650 delivers a captivating listening experience across all genres and volumes, ensuring endless hours of musical enjoyment. Featuring premium features like dual AKM AK4497EQ DACs, Spotify Connect, TIDAL Connect, Qobuz, Roon Ready, Airplay, and more, the DMS-650 offers unparalleled connectivity and performance. Elevate your audio journey with Cary Audios DMS range the ultimate choice for discerning audiophiles seeking innovation and excellence.

Cary Audio

Since its founding in 1989, Cary Audio has stayed at the forefront of home entertainment equipment by stubbornly adhering to the principles of quality and musicality upon which it was founded. Its not enough just to be able to build great-sounding gear, but it needs to be well-made, reliable and maintain its performance and value for many years.

Cary Audio has evolved into a powerhouse offering solid-state home theatre and digital source gear.  Their commitment to quality and performance remains unwavering as they continue to push boundaries with cutting-edge innovations.

Technical Specifications

Master Clock Jitter
Below measurable levels

Digital Sampling Rates (Fs)
44.1 kHz to 768 kHz, DSD64 to DSD512

Digital Filter
32-Bit 8x Oversampling Digital Filter

Digital/Analog Converters
2 2 channel AK4497EQ for true balanced output

Bluetooth
CSR Bluetooth v4.0 with aptX® HD for 24-Bit / 48 kHz high-definition audio decoding

Analog Filter
3rd Order Bessel

Analog Outputs
Balanced XLR, Single-Ended RCA

Digital Outputs
Coaxial operating at Sample Frequency (Fs) from 44.1 kHz to 386 kHz, 16-bit to 24-bit, DSD64, DSD128
Toslink operating at Sample Frequency (Fs) from 44.1 kHz to 192 kHz, 16-bit to 24-bit, DSD64

Digital Inputs
USB x3, SD Card x1
Bluetooth x1
AES/EBU x1, Coaxial x2, Toslink x1

Digital Input Sample Rate
USB/HDD operating at Sample Frequency (Fs) from 44.1 kHz to 768 kHz, 16-bit to 32-bit, DSD64, 128, 256, 512
Bluetooth Sample Frequency (Fs) 48 kHz, 24-bit
AES/EBU, Coaxial operating at Sample Frequency (Fs) from 44.1 kHz to 384 kHz, 16-bit to 24-bit, DSD64 to DSD128
Toslink operating at Sample Frequency (Fs) from 44.1 kHz to 192 kHz, 16-bit to 24-bit, DSD64

Control
Trigger input 12VDC x1
IR control x1

Communication
Ethernet RJ45 full remote configuration interface
Wi-Fi 802.11 b/g/n/ac support MU-MIMO

Power Input
Configured at factory for either 110120V or 220240V AC, 5060 Hz

AC Power Requirements
45 Watts

Finishes
Black
Silver

Weight
13 kg

Dimensions
95 x 438 x 413 mm (H x W x D)

AUDIO (LPCM)

Frequency Range
2 Hz 22 kHz (44.1 kHz)

Amplitude Linearity
0.1 dB (20 Hz 20 kHz)

Phase Linearity
3 degrees (20 Hz 20 kHz)

Dynamic Range
121 dB (1 kHz) XLR OUT

Signal-to-Noise Ratio
115 dB (1 kHz)

Channel Separation
107 dB (1 kHz)

Total Harmonic Distortion
0.0004% (1 kHz)

Audio Output Level
2.0V RMS (220 output impedance) for Volume at 0.0dB
3.0V RMS (220 output impedance) for Volume at +8.0dB

Balanced XLR Output
+/- 2.0V RMS (440 output impedance) for Volume at 0.0dB
+/- 3.0V RMS (440 output impedance) for Volume at +8.0dB

NETWORK, USB & SD CARD PLAYBACK

Playback Format Support
.dsf, .dff (DSD64, 128, 256, 512), .aif, .aiff, .alac, .flac, .m4a, .mp4, .wav, .ape, .mp3, .aac, .wma, .ogg, .asf

Frequency Range
2 Hz 100 kHz +/- 3.0 dB

Signal System
16, 20, 24 & 32-bit PCM and 1-bit DSD

Sampling Frequency
44.1 kHz to 384 kHz PCM and 2.822 MHz 22.5792 MHz DSD

Dynamic Range
121 dB @1kHz XLR OUT

DSD System Clock Frequency
22.5792 MHz

Signal-to-Noise Ratio
115 dB

Audio Output Level
2.0V RMS (220 output impedance) for Volume at 0.0dB
3.0V RMS (220 output impedance) for Volume at +8.0dB

Balanced XLR Output
+/- 2.0V RMS (440 output impedance) for Volume at 0.0dB
+/- 3.0V RMS (440 output impedance) for Volume at +8.0dB

SPDIF PLAYBACK COAXIAL, TOSLINK & AES/EBU (LPCM)

Frequency Range
2 Hz 100 kHz +/- 3.0 dB

Signal System
16, 20 and 24-bit

Sampling Frequency
44.1 kHz to 768 kHz PCM, DSD64, DSD128

Dynamic Range
121 dB @1kHz XLR OUT

System Clock Frequency
22.5792 MHz

Signal-to-Noise Ratio
115 dB

Audio Output Level
2.0V RMS (220 output impedance) for Volume at 0.0dB
3.0V RMS (220 output impedance) for Volume at +8.0dB

Balanced XLR Output
+/- 2.0V RMS (440 output impedance) for Volume at 0.0dB
+/- 3.0V RMS (440 output impedance) for Volume at +8.0dB
*This information has been obtained from Manufacturers website. We advise that Features, Specifications & Price are subject change without notice.

E&OE
